Delay Off Time Relay 16A Adjustable GRT8-B1, Electronic Time Delay Relay in Din Rail, 0.1s-10 Days Wide Range Factory Automation Relays Timer Universal Voltage GRT8-B1 AC/DC 12V 240V
Product details
| Management number | 228191233 | Release Date | 2026/05/31 | List Price | $10.40 | Model Number | 228191233 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- FUNCTION MODE: control the closing or opening of the circuit through the time delay function of the relay, GRT8-A series, Delay On device, GRT8-B series, Delay Off device
- PARAMETER RANGE: number of outputs：1SPDT（1NO 1NC） rated current: 16A rated voltage: AC DC 12V to 240V (50-60Hz) (power supply allowable range: -15%; +16%) timer delay off range: 0.1s-1s/1s-10s/6s-60s/1min-10min/6min-60min/1h-10h/0.1d-1d/1d-10d
- USE & STATUS: ac dc 12v time delay relay first knob is for delay time gear selection, and the second knob is for time percentage multiples, delay off timer relay dc 24v green indicator light indicates the relay power supply, and the red indicator light indicates the delay and contact status
- MATERIAL & SIZE: din rail timer relay uses an ABS plastic sealed housing and complies with CE, CB, and RoHS, timer relay 120v measures 2.88 inches x 3.68 inches x 0.9 inches, weighs approximately 2.65 ounces, and is mounted on a 35 mm Din rail.
- WORRY FREE AFTER-SALES SERVICE: We provides a 30 day no reason return and a 3-year warranty for this product. If you have any questions about installation or use, or if you encounter any problems during use, please feel free to reach up to us at any time
| ASIN | B0DYVGT6ZB |
|---|---|
| Model | GRT8-B1 AC/DC 12V-240V |
| Brand Name | IGEYAPA |
| Part Number | GRT8-B1 AC/DC12V-240V |
| Contact Type | Normally Open |
| Manufacturer | IGEYAPA |
| Mounting Type | DIN Rail Mount |
| Connector Type | Screw |
| Current Rating | 16 Amps |
| Operation Mode | Manual |
| Contact Material | Copper |
| Specification Met | CCC, CE, RoHS |
| Included Components | 1pcs delay off timer relay GRT8-B1 AC/DC 12V-240V+*1 using munual |
| Upper Temperature Rating | 131 Degrees Fahrenheit |
| Maximum Switching Current | 16 Amps |
| Maximum Switching Voltage | 240 Volts |
| Minimum Switching Voltage | 12 Volts (DC) |
